How much faster are screw pile foundations compared to concrete?

Screw pile foundations install 50-70% faster than concrete. No excavation, no formwork, no concrete curing time. The pile screws in, carries load immediately, and construction can start the same day.

How much do screw piles cost compared to concrete foundations?

Screw piles can reduce total foundation cost by up to 50%. Savings come from eliminating frost insulation, drainage, shorter piles that reach capacity at shallower depths, fewer work phases, and fewer invoices.

Can screw piles be installed year-round?

Yes, screw piles can be installed in any season, including winter. They do not require concrete curing, so frozen ground and cold temperatures do not prevent installation.

What load capacity do screw piles support?

Screw piles support loads from 10 kN to over 1,000 kN depending on pile size and soil conditions. They handle both compression and tension (uplift) loads, making them suitable for solar farms, buildings, and infrastructure.

Do screw piles cause vibration or noise during installation?

No. Screw piles are screwed into the ground with minimal vibration and low noise, making them safe to install near existing structures, in residential areas, and in environmentally sensitive locations.

What types of projects use screw pile foundations?

Screw piles are used for solar farms, BESS installations, buildings, industrial construction, road and rail infrastructure, residential housing, noise walls, bridges, and challenging terrain including peat bogs, clay, and remote sites.

Why Screw Piles

Your foundation ready in hours, not weeks

Q: What is the environmental impact of screw piles versus concrete?

Screw piles produce 78% lower CO2 emissions than concrete foundations. Zero concrete eliminates the single largest carbon source in foundation work. Screw piles are 100% steel, 100% removable, and 100% recyclable.

Skip the excavation, the concrete, and the curing time.

Benefits Comparison Applications Certifications

Advantages

Why construction professionals choose screw piles

Three measurable advantages that change your project economics. Every claim backed by real site data.

50–70%

Faster project delivery

No excavation, no formwork, no concrete curing. The pile screws in, carries load immediately, and your build starts the same day.

Up to 50%

Lower total foundation cost

No frost insulation, no drainage, shorter piles that reach capacity at shallower depths. Fewer work phases, fewer invoices.

78%

Lower CO₂ emissions

Zero concrete eliminates the single largest carbon source in foundation work. 100% steel, 100% removable, 100% recyclable.

No vibration, no noise – safe near existing structures

Full load capacity from minute one

Install year-round, any season

10 to 1,000+ kN capacity range

Hand drill or excavator – scales to any project

Tight sites, slopes, and remote locations

Let's find the right foundation for your project.

01444 223 755

hello@ukhelix.com

Head to head

How your options compare

Most foundation decisions are still made out of habit. Concrete has been the default for so long that many project teams never stop to compare. Here is how the options stack up.

Factor	Screw piles	Concrete foundations
Excavation & haulaway	None required	Extensive earthworks + soil disposal off-site
Soft soil (peat, clay)	Installs directly, no soil replacement	Often requires costly soil replacement
Drainage	Not required	Typically required
Frost insulation	Not required	Typically required
Work steps	Single operation: screw into ground	Excavation, formwork, reinforcement, pouring, curing, backfill
Installation time	Hours to days	Weeks (excavation + formwork + reinforcement + curing)
Weather dependency	Installs year-round in most conditions	Concrete cannot be poured in freezing conditions
Noise & vibration	Minimal noise, no ground vibration	Heavy machinery on site
Load-bearing	Immediately after installation (torque-verified)	Requires curing period (typically 28 days for full strength)
Load direction	Compression and tension (both directions)	Primarily compression
Removability	Fully removable and reusable	Permanent, removal requires demolition
Environmental impact	Recyclable steel, no excavation waste, smaller footprint	Higher material consumption, excavation waste

Factor	Screw piles	Driven steel piles
Site preparation	Compact equipment, minimal site prep needed	Heavy rigs require prepared access roads and working platforms
Equipment	Standard excavator or handheld drill (HELIX)	Specialized heavy piling rig required
Noise & vibration	Minimal noise, no ground vibration	Significant impact noise and ground vibration
Residential areas	No disturbance to neighbours	Significant noise and vibration disturbance
Night work	Quiet operation allows night-time installation	Noise levels prevent night-time work
Nature & nesting areas	Low-impact, suitable near protected areas	Not suitable near nature reserves or nesting sites
Pile length	Shorter: helical flange reaches capacity at shallower depth	Longer piles needed to achieve same capacity in loose soils
Material usage	Less steel per pile, lower transport and material cost	More steel required, higher material and logistics cost
Tension / uplift	Excellent uplift resistance thanks to helical flange	Poor tension and uplift resistance
Removability	Fully removable and reusable	Permanent, extraction is destructive and costly
Environmental impact	Less material, smaller footprint, recyclable	More material consumption, higher carbon footprint

Factor	Screw piles	CFA piles
Equipment	Standard excavator or handheld drill (HELIX)	Heavy CFA rig and concrete pump
Site preparation	Compact equipment, minimal site prep	Access roads, working platform, concrete delivery logistics
Work steps	Single operation: screw into ground	Auger drilling, concrete pour as auger withdraws, reinforcement cage insertion
Concrete requirement	None	Every pile is cast in-situ with concrete
Installation time	Hours to days	Days to weeks (including curing)
Load-bearing	Immediately after installation (torque-verified)	Only after concrete curing (typically 7–28 days)
Capacity verification	Real-time torque measurement during installation	Integrity testing and load test after curing
Weather dependency	Installs year-round in most conditions	Concrete cannot be poured in severe frost
Noise & vibration	Minimal noise, no ground vibration	Rig noise, concrete truck traffic on site
Soft & challenging soils	Installs through soft soil layers to reach bearing stratum. No bore stability concerns.	Bore collapse risk in soft soils and high water table. Uncontrolled concrete overbreak increases material cost. Often requires casing support.
Tension / uplift	Excellent uplift resistance from helical flange	Limited tension capacity without additional anchoring
Material usage	Steel only, no concrete	Steel reinforcement cage + concrete per pile
Quality assurance	Torque log per pile, immediate verification	Dependent on concrete quality, curing conditions, bore stability
Removability	Fully removable and reusable	Permanent, cannot be extracted
Tight access sites	Compact equipment reaches confined spaces	Large rig footprint, limited manoeuvrability
Environmental impact	Recyclable steel, no excavation waste, smaller footprint	Concrete + steel, spoil arisings, larger carbon footprint

Factor	Screw piles	Ground screws
Capacity verification	Torque-to-capacity correlation (K_t × T) gives real-time verification during installation	No established torque correlation; capacity typically requires individual load testing
Tension / uplift	Engineered for both compression and tension thanks to helical bearing plate(s)	Limited pullout resistance from shaft friction only; not engineered for structural tension loads
Load range	10 to 1,000+ kN, pile diameters 60.3 to 323.9 mm (PRO series)	Typically under 100 kN
Frost heave resistance	Helix installed below frost line; slim shaft through frost zone minimises adfreeze	Typical length 0.6–1.5 m: often entirely within the frost zone in Nordic conditions
Extendability	Bolt-on extensions to reach required depth (30+ m possible)	Fixed length, not extendable
Corrosion protection	Hot-dip galvanised per EN ISO 1461, traceable SSAB steel	Varies by manufacturer: electroplating, paint, or hot-dip galvanising
Helix / plate diameter	200 to 800 mm true helical bearing plates	150 to 250 mm threads or small flanges
Installation documentation	Per-pile torque log, capacity data, full traceability	Typically no per-unit installation documentation
Standards & design	EN 1090 CE, design per EN 1997, coating per EN ISO 1461	Varies by manufacturer; some hold product-specific ETA with design tables
Typical applications	Buildings, industrial halls, infrastructure, solar farms, masts	Fences, carports, small decks, signs, small-scale solar

Applications

No excavation, no concrete, no trace
Works even in soft soil conditions
Fully removable, site returns to original state
Install with compact equipment in tight spaces

Back

Quality & Standards

Built to European standards

Every screw pile you receive from Paalupiste is designed and manufactured in Finland, and documented to meet European structural certification requirements.

CE Certified EN 1090 manufacturing

ISO

ISO 9001 & 14001 Quality & environmental

Eurocode Design Full structural calculations

HDG

Hot-dip Galvanized EN ISO 1461 coating

CO₂

Low-carbon steel Among the world's lowest-carbon steel

50+

50–100 year service life Residential & commercial

DOC

Full traceability Installation documentation per pile
